TFS50
Products Features:
✦Metallic case, new design with touch keypad, slim and elegant,2 inch Touch Key Fingerprint accces control device with Aluminum alloy Case
✦Applied capacitive fingerprint sensor, which is good at recognizing live finger and long lasting use
✦Support T9 input method, ID and IC card swiping together
✦Standard TCP/IP, RS485, USB, U disk for communication with computer and server together.
✦Support self-service report. You can export and import user information and shift setting in excel format. It also support export excel attendance report from device directly with USB flash drive.
✦Professional access control, Tamper alarm, duress alarm, door open alarm, Wiegand input and output, door magnetic detection, anti-passback, interlock, fire linkage and other professional access control functions
✦IP 67 Waterproof standard(optional)
| Model | TFS50(Network Biometric Access Control System) |
| Working | Standalone or Network |
| Identification Style | Fingerprint/Password/Mifare/ID |
| Identification Speed | <1 sec |
| FAR | <0.01 |
| FAR | <0.0001 |
| Fingerprint Capacity | 3000 |
| Card Capacity | 3000 |
| Display | 2.0 TFT Color LCD |
| Language | English/Spanish/Turkish/Arabic/Thai/French and so on |
| Communication | WAN remote/RS485/TCP/IP/USB/Wifi |
| Humidity | 20%-60% |
| Temperature | 0℃-40℃ |
| Time Zone and Groups | 8 time zones and 8 time groups, 5 combinations |
| Wiegand out | Wiegand 26&34 |
| Input | Door sensor, exit button |
| Output | Electric Lock |
| Alarm | Defend, Unlock and Threaten |
| Voice | Boom,Dual LED |
| Power Supply | DC12V |
| Anti-passback | In&out door |
| Size | 140*44*20mm |
| Other Functions | WiFi/IP 67 Waterproof (optional) |
